AGC Raywall 90T 8 mm glass

AGC Raywall 90T 8 mm glass, thickness 8 mm, custom made

(more information)

Art. no.

300440

€165.00

per m²

Delivery: Sorry, this product is currently not in stock :-(

GlasBoertje.nl is aangesloten bij Webshop Keurmerk 1800 beoordelingen bij Kiyoh

9.3

Free shipment from € 500,- (incl. VAT)
Pick-up in NL or delivery in NL and Flanders (exception of the Wadden Islands)
Relatively short delivery times
Pay with i.e. iDeal, Riverty, Billink, Bancontact, PayPal en Creditcard

Details

Due to supply problems with our manufacturer, this product will only be available again from approximately the end of May 2025

AGC Raywall 90T 8 mm glass is a type of patterned glass that is characterized by a pattern of many fine dots that have been rolled into the glass in an involuntary pattern. Because of this fine pattern, light does come through the clear glass, but you do not see details and only contours.

This type of glass has been around since 2003 and resembles Canalé glass. The advantage of Raywall is that it can be hardened. This is in contrast to Canalé glass, which cannot be hardened.

This glass is not tempered/hardened, but we can also produce this in a tempered version. Please select another product if you need tempered glass.

Features AGC Raywall 90T 8 mm glass:

Clear patterned tempered glass (transparant but you only see contours, no clear picture)
Can be combined with insulation glass and can be tempered
Suitable for indoor and outdoor use
Standard unfinished/sharp edges, optional polished edge finishing
This glass weighs 20 kg per m²
The mentioned price is a m² price
Can be custom-made in the glass configurator
Maximum size is 1840mm wide, 3340mm high, with a VERTICAL pattern (like the product image)

AGC Raywall 90T 8 mm glass is provided by us:

Custom made
Delivered according to specified specification (note! For glass production tolerances apply!)
Delivered at delivery address. Pick-up is also possible, the options are mentioned on the payment page

Points of attention for tempered Raywall 90T 8 mm glass:

The pattern of this glass is vertical. Please take this into account when you place the order; state the width and height in the right place of the model
You are responsible at all times for applying the safety standards and requirements applicable in your country! In the Netherlands, this includes NEN-3569:2011 (“Vlakglas voor gebouwen – Risicobeperking van lichamelijk letsel door brekend en vallend glas – Eisen” voor Nederland)
For the production of custom glass, tolerances have been determined within the glass industry in terms of dimensions, quality and finish. These are industry-wide and are used by all glass companies. Please note that it is possible that glass may have a small size deviation (approx. 1 - 2 mm), and certain miniscule damages cannot always be claimed
Think carefully about the right glass size. Size changes are no longer possible once your order has gone into production
Within the glass industry it is customary to calculate a minimum area per piece. This is necessary because the handling of an order is always necessary and this prevents a glass plate from costing € 1.50, for example, while the actual production costs are much higher. The minimum area to be calculated differs per product and is stated under the tab "More information" on the product page

more information

more information
Art. no.	300440
Glass thickness in mm	8
Glass color	clear
Minimum glass size	90 x 90 mm
Maximum glass size	1840 x 3340 mm
Expected delivery time	Sorry, this product is currently not in stock :-(
Scope of supply	custom size
Unit of measurement	per m²
Packaging	unpackaged
Shipping price NL	39,50
Shipping price BE	39,50
Shipping price EU	this product can only be sent to NL and BE
Pick-up possible?	yes, Pick-up is possible in:, Oosterhout (Noord-Brabant), 's-Hertogenbosch, (always place orders on the website)
Minimum m² (per piece)	0.35

Downloads

FAQ / Frequently Asked Questions

Delivery & pick-up

Can my order be delivered?

Sure! We deliver throughout the Netherlands and the Dutch-speaking part of Belgium. Glass comes with special glass transport; a van or truck where glass can be placed in the inside and outside. This way you are assured of optimal transport and that your order is delivered properly. The risk of breakage and / or transport damage is entirely at our risk (including delivery to your home). Another guarantee that you will receive your order neatly and undamaged. We always deliver on the ground floor and up to the front door. We don't deliver in apartment floors, even if there is an elevator available.

You can specify two addresses in your order, your billing address and delivery address. This makes it easy to have your glassware delivered where you need it. And when you are logged in, you can enter multiple delivery addresses, which is useful if you are an entrepreneur and need glass at changing locations.

When do we deliver?

To ensure efficient glass transport, we deliver according to fixed routes. The card contains numbers, these are the first two numbers of your zip code. The color on the map represents a route day. In the legend you can see which color belongs to which delivery day. If the delivery concerns separate parts (and therefore no glass products), we will engage the parcel service for this. These often deliver your package within 1-3 working days. If there is a track-and-trace code, we will send it to you so that you can track your package. Check the product pages for an indication of production / delivery time.

The delivery of glass items can be compared to the delivery of a washing machine or a sofa. It is a durable and delicate product that you don't just have delivered with the parcel service. It is neatly delivered and it is desirable that someone is present at the time of delivery. You will receive the delivery date by email immediately after we have received confirmation of delivery. 1-2 working days before delivery, we will send you another update with a time indication of the delivery.

If you cannot be at home, there are plenty of other possibilities to think of; we can deliver the order to the neighbors, put it in the back of the garden, under a carport, in the shed or any other place that you consider safe, postpone the delivery for a week, etc. etc. But please report this to us in time so that we can give the driver clear instructions in advance. This prevents last-minute research when the driver is at your door and no one is found. If the driver does not meet anyone at the delivery and does not know what to do with the order, he will take the stuff back and the delivery will be postponed for a week. Unfortunately, we are then forced to pass on the transport costs for this extra delivery.

Can I also collect my order?

That is also possible! Please indicate when you complete your order that you would like to collect the order. The collection locations are listed on the payment page. As soon as your order is ready, we will inform you about the collection options, times etc. etc. There are a number of collection locations that charge costs for receiving your order and the handling for collecting your order. The loose products (non-glass products) are not in stock at all pick-up locations and we have to send them to you. We unfortunately have to pass these shipping costs to you. These are also stated on the payment page, as a total under the cancellation costs of the collection locations.

A number of pick-up locations are limited in opening hours. These are business locations that have normal office hours and some locations are closed on Friday afternoon at 3:00 PM. Keep this in mind if you choose to pick up location. Pick up at GlasBoertje is of course also possible, we are more flexible in terms of times.

If you choose the collection option, it is obvious that the risk of breakage and / or damage during collection is also transferred. So check your order carefully before you take it with you.
